Описание
.jpg)
.jpg)
|
Model |
WI-PMS552F |
|
Hardware Specifications |
|
|
Interface |
48x10/100/1000Mbps PoE+ Ports 1xConsole Port
4x10G SFP Slots
|
|
Port Standard |
IEEE 802.3 IEEE 802.3u 100BASE-TX
IEEE 802.3ab1000BASE-T
IEEE 802.3x
IEEE 802.3ae: 10 Gigabit Ethernet over fifiber
IEEE 802.3af/at
IEEE 802.3ad
IEEE 802.3q、IEEE 802.3q/p
IEEE 802.1w、IEEE 802.1d、IEEE 802.1S
|
|
PoE Standard |
802.3af/at |
|
PoE Ports |
48, up to 30W per port |
|
PoE Power Budget |
565W |
|
Power Supply |
Built-in switching power supply: AC 100~240V 50/60HZ |
|
Power Consumption |
Full loading without PoE ≤ 35W |
|
Switching Capacity |
176 Gbps |
|
Packet Forwarding Rate |
184.64Mpps |
|
Jumbo Frame |
16kB |
|
MAC Address Table |
16K |
|
Fan Quantity |
2 |
|
DDR |
2G DDR3 1333MHz |
|
FLASH |
64M |
|
DRAM |
256M |
|
Dimensions( W x D x H ) |
Product Size: 440mm*360mm*45mm Package dimensions: 553mm*403mm*95mm
|
|
Net weight/gross weight |
5.6kg/6.45kg |
|
Protection Level |
Port lightning protection：4kV 8/20us Protection class：IP30
|
|
Transmission Method |
Store— Forward |
|
Installation |
Rack- Mounted |
|
Environment |
Operating temperature/humidity：-20～+55°C；5%～90% RH no condensation Storage temperature/humidity：-40～+75°C；5%～95% RH no condensation
|
|
Certification |
CE, FCC, RoHSUACK |
|
Spanning Tree
|
802.1d STP |
|
802.1w RSTP |
|
|
802.1s MSTP |
|
|
Reliability
|
Port Loop Detection |
|
EAPS |
|
|
ERPS |
|
|
LLDP/LLDP-MED |
|
|
UDLD |
|
|
VLLP |
|
|
VLAN
|
Max 4K VLAN Groups |
|
802.1q-based VLAN |
|
|
MAC address based VLAN |
|
|
IP address based VLAN |
|
|
Protocol-based VLAN |
|
|
Voice VLAN |
|
|
QinQ |
|
|
VLAN mapping |
|
|
Port-based VLAN |
|
|
Port
|
Close and open ports |
|
Port auto-negotiation |
|
|
broadcast storm control |
|
|
port mirroring |
|
|
port speed limit |
|
|
Link aggregation (up to 32 aggregation groups are supported, each group supports up to 8 ports) |
|
|
Port isolation |
|
|
Jumbo Frame |
|
|
LACP |
|
|
Security
|
Support opening and closing TELNET, WEB and SNMP services Support TELNET, WEB and SNMP services to bind with standard IP ACL
|
|
CPU protection |
|
|
Support 802.1x protocol Support RADIUS protocol
Support authentication, authorization and accounting through RADIUS server
Supports port-based and MAC-based 802.1x
|
|
|
IP MAC address binding |
|
|
Prevent ARPSpoofing |
|
|
DHCP Snooping(Supportfixed port connection to DHCP server, prevent private connection to DHCP server)
|
|
|
Access Control List
|
Standard IP based ACL |
|
ACL based on extended IP |
|
|
ACL based on MAC IP |
|
|
ACL based on MAC ARP |
|
|
ACL port filtering |
|
|
time-based ACL |
|
|
QoS
|
8 priority queues |
|
Support WRR, RR, WDRR, SP scheduling mode |
|
|
Based on 802.1p classification |
|
|
DSCP-based classification |
|
|
ACL-based classification |
|
|
L2 Multicast
|
Support static multicast MAC address |
|
Support IGMP SNOOPING v1/v2/v3 |
|
|
Support for IGMP Querier |
|
|
Support IGMP Snooping filtering |
|
|
MVR |
|
|
GMRP |
|
|
IPv6
|
IPv4/IPv6 Dual Protocol Stack |
|
Support manual address configuration |
|
|
Supports manual address configuration and stateless address auto-configuration |
|
|
IPv6 Neighbor Discovery |
|
|
ICMPv6 |
|
|
IPv6 Path MTU Discovery |
|
|
L3
|
Static ARP |
|
Static Route(Support static route based on IPv4 and IPv6) |
|
|
VLAN Interface(Support 32 VLAN interfaces) |
|
|
Policy Route |
|
|
VRRP |
|
|
DHCP
|
DHCP Client |
|
DHCP Snooping |
|
|
DHCP Relay |
|
|
DHCP Server |
|
|
DHCP option 82 |
|
|
Management
|
CLI Management(Support Console, Telnet and SSH) |
|
WEB Management |
|
|
SNMP Management: Support SNMP v1, v2c, v3
Support SNMP TRAP
Support lots of standard and private MIBs
|
|
|
TACACS+: support switch authentication via TACACS+ server remote username and password
Support password encryption in PAP and CHAP mode
Support TACACS+ server to authorize the switch's commands
|
|
|
Log Management: Support local log management Support SYSLOG
|
|
|
RMON:Support RMON 1, 2, 3 and 9 groups |
|
|
Configuration file: Support uploading and downloading configuration files
Support TFTP transmission based on IPv4 and IPv6
|
|
|
Upgrade software: Support TFTP transmission and WEB upgrade |
|
|
Clock Management: Support local clock management Support SNTP
|
|
