● L2 managed PoE switch
● 4*10/100/1000 Base-T PoE+ RJ-45 ports and2*1000/2500 Base-X SFP slot
● Complies with IEEE 802.3af/at 30W PoE standard
● Support robust L2 managed function, such as such as VLAN, VLAN classification, QinQ, port mirroring, STP, RSTP, MSTP, IGMP, QoS, DHCP, multicast, ACL, dying gasp,LLDP, 802.1X, fiber transceiver DDM, PoE management, G.8032 ERPS protocol, IPV6 management
● - 40℃~75℃ operating temperature
● 6kV surge immunity for power and Ethernet ports
Model
|
SP3006FM-L2
|
Interfaces
|
Downlink Ports
|
4*10/100/1000 Base-T PoE+ RJ-45(Auto-MDI/MDI-X)
|
Uplink Ports
|
2*1000/ 2500 Base-X SFP
|
Management port
|
1*RJ45 Console
|
PoE
|
PoE Standard
|
IEEE 802.3af/at (PSE)
|
PoE Power Supply Type
|
End-span
|
PoE Pin Assignment
|
1/2(+)，3/6(-)
|
PoE Power Output
|
46~55V DC
|
PoE Power
|
30W max for each port, 120W max
|
Switch Property
|
Standards
|
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Ethernet
IEEE 802.3ab 1000Base-T Ethernet
IEEE 802.3z 1000Base-X Ethernet
IEEE802.3x Flow Control and Back Pressure
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1Q VLAN
ITU-T G.8032 ERPS
IEEE 802.1X Port Authentication Network Control
IEEE 802.1ab LLDP
IEEE 802.3ad LACP IEEE802.3af PoE
IEEE802.3at PoE plus
|
Forwarding Modes
|
Store and Forward
|
Packet Buffer
|
2Mbit
|
MAC Table
|
16k
|
Switching Capacity
|
12Gbps
|
Packet Forwarding Rate
|
8.9Mpps
|
Jumbo Frame
|
10kB
|
Power Supply
|
Input Voltage
|
Power 1 (Main): 44~57V DC, Power 2 (Backup): 44~57V DC
|
Power Consumption
|
Full loading without PoE ≤ 8W PoE power budget ≤ 120W
|
Connector
|
Removable 4-pin terminal block
|
Reverse polarity protection
|
Support
|
Over-voltage protection
|
Support
|
Over-current protection
|
Support
|
Environmental Reliability
|
Industrial Standard
|
Surge protection of power: IEC 61000-4-5 6kV/4kV（8/20us）
Surge protection of Ethernet ports: IEC 61000-4-5 6kV/2kV 10/700us
RS: IEC 61000-4-3 80 MHz-1 Ghz: 10 V/m
EFT: IEC 61000-4-4 4k/2k
CS: IEC 61000-4-6 10V
ESD: IEC 61000-4-2 Contact: 8kV; Air: 15kV
EMI: FCC Part 15B Class A
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
|
Operating Temperature
|
-40℃~75℃
|
Storage Temperature
|
-40℃~85℃
|
Operating Humidity
|
5%~95% (Non-condensation)
|
LED Indicators
|
P (Power indicator)
|
Off: the device is power off or failed Green On: the device power on is normal
|
S (System status indicator)
|
Blinking: device initialization
On: device on and normal operation
|
Copper ports
|
1-4 Green indicators
Off: ports link down
On: ports link up Blinking: data on TX/RX
1-4 Yellow indicators
Off: PoE not working
On: PoE working
|
Fiber ports
|
5-6 Fiber ports indicators
Off: ports link down Green
On: ports link up
Blinking: data on TX/RX
|
Dimensions (W*D*H)
|
54*115*158mm
|
Net Weight
|
