HARDWARE FEATURES

WI-POE60-24V

Hardware Version

V1

L2 Managed

No

Interface

2 100/1000Mbps RJ45 Ports

PoE Port

PoE IN: 802.3af/at 48-52V

PoE OUT: Passive 24V

Network Media

10BASE-T: UTP category 3, 4, 5 cable (Max 100m)EIA/TIA-568 100Ω STP (Max 100m)

100BASE-TX: UTP category 5, 5e cable (Max 100m)EIA/TIA-568 100Ω STP (Max 100m)

1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)

Fan Quantity

Fanless

Power Consumption

30W

External Power Supply

DC IN 37-57V

Exchange Capacity

2Gbps

Packet Forwarding Rate

14.9Mpps

Mac Address Table

2K

Packet Buffer Memory

1Mb

Jumbo Frame

10240 Bytes

Protection Level

4kV Lightning protection 4kV ESD Contact discharge

Transmission Method

Store-And-Forward

Advanced Functions

Mac Address Auto-Learning And Auto-Aging Store and forward

IEEE 802.3x flflow control for Full-duplex Mode

Backpressure for Half-duplex Mode

OTHERS

Certification

CE, FCC, RoHS

Package Dimension

116×44×29 mm

Switch Dimension

112×40×25mm

Gross Weight

0.03kg

Net Weight

0.025kg

Package Contents

1 × PoE Converter

Working Environment

Working Temperature: -10℃~55℃

Storage Temperature: -40℃~70℃

Working Humidity: 10%~90% RH

non-condensing Storage Humidity: 5%~90%

RH non-condensing
